Nicon Self Centring Compact High Grip Vice - N-110
FEATURES:
- Self centring compact hi-grip machine vice designed for precision milling, grinding and widely used with CNC machining center.
- Space saving design can be installed in multiple on standard machine table.
- Also suitable for 4th and 5th axis CNC rotatry tables.
- Large opening in very compact vice body.
- This vice can hold two work pieces with optional intermediate jaws.
- High grade FCO 60 ductile iron body, grounded top and bottom.
- Bed height matched with multiple vice orders.
- High alloyed quality resistance stress, case hardened HRC 60 +or- 2 is used in clamping jaws give high preferences and no wear.
- Accuracy in parallelism and squareness within 0.02/1mm.
- Interchangeable jaws plates.
- Tenon & tenon slots are provided for effortless truing of vice on the machine table.
- High clamping force can be achieved by effortless handle movement, which eliminates hammering on vice handle.
- Maximum clamping force 3000kg.
STANDARD ACCESSORIES:
- 1 Adjustable handle
- 1 pair of positioning key nuts
- 1 Wok stopper
DIMENSIONS IN MM:
